Home >   Course Catalog >   The Stability Pyramid

Watch Course Preview

The Stability Pyramid Training Short

Watch Course Preview

Learn how load height affects forklift stability through the Stability Pyramid.

1 minutes   |   SKU: ATS077-3    |    Language(s): EN    |    Produced 2023

SKU:

ATS077-3

Language(s):

EN

Updated:

2023

Length

1 minutes

Training Objectives

Explain how load height affects forklift stability
Apply practices to maintain stability when lifting loads

Course Overview

While the Stability Triangle explains forklift balance on a flat surface, real-world operation also involves height. This three-dimensional concept is known as the Stability Pyramid. It helps operators understand how raising or lowering a load changes the overall balance of the forklift system.

In this model, the combined center of gravity of the forklift and its load can be imagined as a point suspended within a pyramid-shaped boundary. When the load is kept low, the pyramid remains wide and stable, helping keep the center of gravity securely within safe limits.

However, as the load is raised higher, the pyramid becomes taller and narrower. This reduces the margin for stability and makes it easier for the center of gravity to move outside the safe zone, which can lead to a tip-over. To reduce this risk, operators should always keep loads as low as possible, especially while traveling.

Super Flexible Formatting

You’ll never find yourself scratching your head, trying to figure out why
you can’t get our videos to play or courses loaded into any platform.

Access courses
in our EHS Software.

View this course in a classroom
environment, or assign it to your
team individually with testing
and recordkeeping capabilities.

Load courses
into your platform.

Each title includes an embed
feature that allows users to add
videos to their existing training
platform or LMS.

Access courses
in our LMS.

View this course in a classroom
environment, or assign it to your
team individually with testing
and recordkeeping capabilities.

Not Ready to Sign Up?
No Worries. Here’s Some Helpful Info.

What is the Stability Pyramid?


The Stability Pyramid is a three-dimensional model that explains how load height affects forklift balance and stability.


Why does raising a load reduce forklift stability?


Raising the load makes the stability zone narrower, increasing the chance that the center of gravity will shift outside safe limits.


Why should loads be kept low while traveling?


Keeping loads low maintains a wider stability base and reduces the risk of tipping the forklift.


What role does the center of gravity play in the Stability Pyramid?


The center of gravity represents the balance point of the forklift and load, which must remain within the stability zone.


How can operators reduce the risk of forklift tip-overs?


Operators should keep loads low, avoid sudden movements, and follow proper load-handling procedures.
