Electricity is a beast, and if you don’t respect it, it will remind you why you should.
Sure, electricity powers everything from your morning coffee maker to entire industries, but it also has a nasty side. One of the most dangerous hazards? Arc flashes. These explosive electrical events generate heat hotter than the sun, send molten metal flying like bullets, and create pressure waves strong enough to knock you off your feet
Arc flashes don’t happen by accident, they happen because something went wrong.
An arc flash occurs when electricity jumps the gap between conductors, creating an explosion. Here’s what causes it:
- Damaged insulation or faulty equipment
- Human error, like dropping a tool near live components
- Improper maintenance or failure to follow safety procedures
Why arc flashes are nothing to mess with
Arc flashes aren’t just some scary spark. They’re full-on electrical explosions capable of causing life-changing injuries:
- Insane Heat: 35,000°F, hot enough to vaporize metal
- Pressure Waves: The blast can throw you across the room and collapse your lungs
- Flying Debris: Molten metal and shrapnel turn into high-speed projectiles
- UV Radiation: The flash alone can permanently damage your eyes
- Toxic Fumes: Vaporized materials can cause severe respiratory issues
Avoiding arc flashes isn’t rocket science, but it does require a plan.
The hierarchy of controls is your playbook for reducing arc flash risks:
1. Eliminate the hazard
If you can de-energize the equipment before working on it, do it. No live electricity, no arc flash
2. Use safer equipment
Upgrading to arc-resistant switchgear and lower-voltage systems can cut your risk significantly
3. Engineering controls
Barriers, remote switching, and insulated tools help keep you safe while working around electrical hazards
4. Administrative controls
Training, strict procedures, and proper communication reduce human error and keep workers aware of the risks
5. Personal protective equipment (PPE)
When all else fails, PPE is your last line of defense. It won’t stop an arc flash, but it might save your life
Risk assessments aren’t optional, they’re your first step toward safety.
Before working on electrical equipment, conduct:
Electric shock risk assessment
Defines danger zones where electrical contact could occur:
- Limited Approach Boundary: Only trained personnel allowed
- Restricted Approach Boundary: Extra precautions are required, including PPE
Arc flash risk assessment
This determines the severity of a potential flash and defines:
- Arc Flash Boundary: Distance where burns are possible
- Incident Energy Levels: Used to determine proper PPE
Tip: Use NFPA 70E guidelines to calculate these boundaries accurately
PPE isn’t optional, it’s mandatory.
Understanding PPE categories
Arc-rated PPE is categorized from 1 (low risk) to 4 (high risk) based on the energy level of a potential arc flash
Essential arc flash PPE
- Head Protection: Arc-rated helmets, face shields, and balaclavas
- Hearing Protection: Arc-rated earplugs to block the sound of the blast
- Body Protection: Flame-resistant clothing, arc-rated coveralls, and underlayers
- Hand & Foot Protection: Leather or insulated gloves and arc-rated boots
Warning: Never wear synthetic materials like polyester or nylon, they melt in an arc flash
Lockout-tagout and de-energization should always be your first move.
De-energizing equipment
- Verify with a tester that no power is present
- Follow strict lockout-tagout procedures
If working live is necessary
- Get an Energized Electrical Work Permit: Justify why live work is required
- Develop a Job Safety Plan: Outline tasks, risks, and emergency actions
- Mark boundaries: Define arc flash and approach limits with barriers
- Check your gear: Ensure PPE and insulated tools are up to spec
Pro Tip: Only use insulated tools rated for the voltage you’re working with
Expand your knowledge with electrical safety training.
This course introduces Electrical Safety: Arc Flash Prevention, but there’s more to learn. For a deep dive into NFPA 70E compliance and advanced protection strategies, enroll in our Electrical Safety: Arc Flash Prevention Training Course
